Model

 GT-SD552

Image Sensor

 1/3" APTINA CMOS

Image Resolution

 1.3 Megapixel

Minimum‑Illumination

 Color：0.1Lux@F1.6, B&W：0.01Lux@F1.6

Day & Night

 IR-Cut

IR distance

 50m

Focus Mode/Gain
Compensation/ White
Balance

 AUTO/Manual

S/N

 >50dB

Backlight Compensation

 On/Off

Aperture

 AUTO/Manual

Lens

 4.63~46.3mmF2.0 (10X optical zoom)

Pan

 360° endless, 0.01-200°/S

Tilt

 -5～92°, 0.01-120°/S

Zoom

 10X optical zoom

Preset Position

 255 preset positions

Video Compression

 H.264

Dual-stream

 Support

Frame Rate

 50Hz:25fps(1280*720) ,25fps(1280×960)
 60Hz:30fps(1280*720) ,30fps(1280×960)

Image Settings

 Brightness, contrast, saturation, color

Security

 Multi-level users access with password protection;
 Authorised users and bound MAC address.

WDR

 Support

Network Interface

 10Base-T/100Base-TX Ethernet interface

Support Protocol

 TCP/IP,HTTP,DHCP,DNS,RTP/RTCP,RTSP,PPPoE,
 SMTP,NTP, FTP, SNMP

Intelligent Alarm

 Motion detection、video and audio recording to
 edge storage

Storage

 Snapshots and video clips

Alarm Event

 Motion detection, video blocked/covered alarm,
 storage space over/wrong

Casing

 Camera: Metal (Aluminum Alloy)
 Transparent cover: High quality PC
 Color: white

Power Supply

 DC12V±10%3A

Power Consumption

 30W MAX

Working Conditions

 -30℃～+65℃,＜90%RH

Protection Rating

 IP65

Net Weight

 1.5kg

Dimension

 141(mm)×215(mm)
