GT-BA510/513/520
  • Supports dual IR-CUT Filter
  • Supports dual video streams
  • Supports auto electronic shutter

Model

GT-BA510

GT-BA513

GT-BA520

Model Name

1.0 MP IR bullet IP camera

1.3 Megapixel IR bullet IP camera

2.0 Megapixel IR bullet IP camera

Image Sensor

1/4" OV9712 CMOS sensor

1/3" AR0130 CMOS sensor

1/3" SONY IMX122 CMOS sensor

Image Resolution

1280×720

1280×960

1920×1080

Min. Illumination

0.1 Lux(IR Off),0 Lux(IR On)

Day/Night Mode

ICR cut fi­lter

Lens

4mm ­fixed lens (6mm and 8mm ­fixed lens optional)

IR Distance

IR projection angle: 60°, 10~15M valid

Main Processor

Hi3518c

OS

Linux

Video Compression

H.264 high pro­file

Bit Rate

32 Kbps~6Mbps

Audio

N/A

Video Resolution

1280*720

1280*960

1920*1080

Intelligent Alarm

Motion detection, video lost, network disconnected, IP address conflict

Video Frame Rate

NTSC:1~30 frame,PAL:1~25 frame

Image Settings

Brightness, contrast, saturation, image rotation

Network Interface

1 * RJ45 10M/100M ethernet port

Power

DC 12V / 1.5A

Max Power Consumption

6W

Work Temp.

-20℃~ 55℃

Net/Gross Weight

0.55kg/0.72kg

Dimension(color box)

  230mm*127mm*127mm

GT-BA510/513/520

0.28 Mb Data Sheet
2015-09-01

GT-BA510/513/520

0.91 Mb Quick Start Guide
2015-09-01
