Product Model

GT-ADR1601M

Video Compression

H.264 (High Profile)

Video Input

Analog: 16* AHD-M; 8* AHD-M;

Mixed:4* AHD-M (analog )+4*720P( network );

Network: 1*1080P+8*720P；4*1080P；20*960H;

Audio Compression

G.711A

Audio Input

2-ch RCA

Video Output

1-ch VGA, 1-ch HDMI

Audio Output

1-ch RCA

Backup

Network backup, USB mobile hard disk

Playback

4 channels (1-ch real time)

Hard Disk Interface

1 SATA (Max to 3TB)

Space Occupied

720P 20G / day*channel; 960H 12~20G / day*channel; Audio: 691.2M / day*channel

Input

16-ch BNC

Network Interface

RJ45 10M/100M adaptive ethernet interface

USB Interface

2 USB 2.0 ports

Serial Interface

1 RS-485 Support multi kinds of PTZ protocol

Power

12V/2A

Dimension(color box)

345mm* 95mm* 275mm

Net/Gross Weight

1.0kg/1.8kg
